Rod Mill

Request a Quote

Yate rod mill is a highly energy-efficient grinding mill. As a selective grinding, the rod mill is different from the ball mill. Its grinding media are made of stainless steel rods. By comparison, the rod mill is generally applied with wet overflow discharge type, which can be used as the first level circuit grinding. Accordingly, it is widely adopted in artificial stone sand, mineral processing plant, chemical plant power department of the first level grinding.

Technical data

Model	Cylinder diameter (mm)	Cylinder length (mm)	Rotational speed (r/min)	Capacity (t)	Motor power (kW)	Weight (t)
MYJ0930	900	3000	32	0.4-4.8	22	7.4
MYJ1224	1200	2400	28	0.4-4.9	37	12.6
MYJ1230	1200	3000	28	0.4-5.2	45	13.4
MYJ1530	1500	3000	26	2.4-7.5	75	17.4
MYJ2130	2100	3000	20	14-35	180	49.2
MYJ2136	2100	3600	20	19-43	210	57.2
MYJ2230	2200	3000	23.6	20-45	245	53.0
MYJ2430	2400	3000	20.6	25-65	280	58.5
MYJ2436	2400	3600	20.6	28-68	280	61.5
MYJ2736	2700	3600	18	32-86	400	84.6
MYJ3245 i	3200	4500	50	64-150	630	130
MYJ3645	3600	4500	167	80-180	1000	150.9
MYJ3654	3600	5400	167	85-200	1250	156

Shenyang Yate is over 20 years of experience in the rock crushing industry. As an experienced rock crushing equipment manufacturer, we can develop and produce portable and economic coarse crushing systems that meet your various needs for the economic and reliable performance in the economic and mobile crushing industry. We are capable of offering mobile stone rock crushers with a variety of configurations to perfectly match different operational requirements. Our rock crushing machines are cost-effective and we are able to handle the entire size reduction process including crushing, grinding, screening, feeding, .etc. Our movable crushing and grinding equipment are also featured with innovative and dynamic crusher processing technologies that can make your material handling more accessible and reachable. So, if you’d like detailed information about our crushing machines and full-service, just feel free to email us or give us a call.
